800x USB Microscope Endoscope 2MP CMOS Sensor with Adjustable Stand 1555.1
- Regular price
- RM 104.90
- Sale price
- RM 104.90
- Regular price
-
RM 0.00
Worldwide shipping
Secure payments
Fast Delivery
Share
USB Digital Microscope Endoscope Magnifier 800X with 2MP Video Camera Adjustable Stand
Descriptions:
Our Digital Microscope 800x type tool and can be easily used in different fields including:
1. Leaf inspection
2. Pistils inspection
3. Pest examination
4. Educational purpose
5. Microbiological observation
Specifications:
- Image Sensor: CMOS
- Controller: High Speed DSP
- Image Sensor: 2.0MP
- Focus Range: 0mm ~ 40mm
- Still Image Capture Resolution: 320*240, 480*320, 640*480, 1280*960, 1600*1200
- Video Capture Resolution: 320*240, 480*320, 640*480, 1280*960, 1600*1200
- Photo Format: JPEG, BMP
- Frame Rate: 30 f/s under 600 LUX Brightness
- Light Source: 8 LED Light (with controller on USB cable)
- Magnification Range: 20X, 800X
- Power Supply: USB Port (5V DC)
- PC Interface: USB 2.0, USB 1.1
- Operation System: Windows XP/Vista, Win 7 32 bit & 64 bit
- Language English, Chinese and other language by selection
- System Requirement: Pentium Computer with 700M Hz & above
- Product Dimension: 13.5cm(L) x 3.3cm(W)
- Color: Black
Hardware System Requirements:
Windows 2000, XP, VISTA, WIN7 Pentium 1G, Celeron, AMD 1G & above, 128MB Memory, 150MB Hard Disc memory space, 16-bit & above VGA, CD-ROM, USB2.0 or USB1.1.
How to Install the Driver:
This digital microscope is a free driver product，it can be worked immediately after connected to the computer with operation system above win2000 version.
1. Connect the portable digital microscope by USB2.0 cable to your computer.
2. Double click ‘my computer’ icon on your computer desktop below interface will be shown up.
Warning:
1. Don’t dissemble the digital Microscope or change the interior parts, it can cause damage.
2. Don’t clean the Microscope with alcohol organic solvents.
3. Don’t touch the lens with your fingers.
4. Avoid outdoor use if possible.
5. In case the product gets wet, leave PC connection immediately. Do not dissemble or dry by hair dryer.
6. Measurement data only for reference.
Package Includes:
1 x 800x Digital Microscope with USB 2.0 Cable
1 x Metal Fixed Stand Kit (The design may be slightly different)
1 x User Manual
1 x Calibration Ruler
1 x CD ROM (Driver Measurement Software User Manual)
Stock No.: 1555.1
